Emdoor EM-I61J: Rugged Industrial Handheld with Windows for Mobile Data Collection

The Emdoor EM-I61J is a compact and rugged industrial handheld running the Windows operating system, designed for mobile data collection, logistics, field service, and fieldwork. Thanks to the combination of the Intel® platform, high durability, and extensive connectivity, it enables efficient use even in demanding operating conditions.

The device is designed for everyday use in industrial settings. It offers reliable performance, a high-quality display with Gorilla Glass protection, and support for modern communication technologies, including LTE and NFC.

Key Features

Performance and Windows Platform

The device uses an Intel® processor and the Windows operating system, enabling easy integration into corporate systems.

Key advantages of the handheld:

• Intel® Celeron N5100 (Jasper Lake) processor
• Windows 10 / Windows 11 (IoT/PRO) operating system
• 8 GB RAM
• 128 GB storage

Display and Controls

The display is optimised for field use with an emphasis on readability and durability.

Key features of the handheld:

• 6.5″ TFT display (20:9 aspect ratio)
• 720 × 1600 resolution
• Brightness up to 500 cd/m²
• Capacitive touchscreen (5-point)
• Corning® Gorilla® Glass

Connectivity and Communication

Extensive connectivity options ensure full mobility and integration into enterprise systems.

Key features of the handheld:

• Wi-Fi 802.11 a/b/g/n/ac (2.4 + 5 GHz)
• Bluetooth 5.0
• 4G LTE
• GPS + GLONASS
• NFC

Data Collection and Interfaces

The device is ready for professional data collection and peripheral connectivity.

Key features of the handheld device:

• Optional 2D barcode scanner
• Interfaces:
  • USB-C (OTG)
  • USB-A (3.0)
  • Nano SIM slot
  • TF card (up to 512 GB)
  • Pogo pin for docking station

Ruggedness for industrial use

The Emdoor EM-I61J is designed for demanding operating conditions.

Key features of the handheld:

• IP67 rating
• MIL-STD-810H compliance
• Drop resistance up to 1.5 m
• Operating temperature: −20 °C to +60 °C

Power and battery life

The device offers sufficient battery life and fast charging for all-day operation.

Key features of the handheld:

• 7.4 V / 4000 mAh battery (removable)
• Battery life of approx. 6 hours (typical use)
• PD 3.0 fast charging support (up to 45 W)

Key benefits of the device

• Full-featured Windows handheld (Intel platform)
• High durability: IP67 + MIL-STD
• Extensive connectivity, including LTE, GPS, and NFC
• High-quality display with protective glass
• Option to add a scanner

Technical specifications

Typical applications

Logistics and Warehousing – Data collection, inventory management, and warehouse system operations.

Service and Maintenance – Equipment diagnostics and service log management.

Transportation and Field Work – Navigation, communication, and task execution.

Industrial operations – Process control and monitoring.

Why choose the Emdoor EM-I61J

✔ Full-featured Windows system in a compact device
✔ High durability suitable for demanding environments
✔ Integrated mobile connectivity
✔ Data collection support (scanner, NFC)
✔ Fast charging and removable battery
